Independence in XXL
With an S20 X PRO, you can supply several homes, charge several vehicles or make an entire business energy-independent. There are practically no limits when it comes to configuration and expansion.
Energy
Management
No subscription, no hidden costs, always free updates and energy management that ensures your electricity is always used and distributed in the best possible way.
Power Package
Peak shaving
With large PV systems and extremely expandable storage, the S20 X PRO meets all requirements.
Emergency Power
The S20 X PRO ensures maximum operational reliability.
Trans-
parency
Full control over all energy balances.
The Unique E3/DC-System
The E3/DC home power station with AI 360° is the heart of a unique system – it intelligently controls the storage system, wallbox and heat pump and actively saves energy costs.
HEATING
More than 150 of our specialist partners integrate electrical heating technology.
All home power stations can control heat pumps and already meet the requirements of §14a EnWG.
ELECTRICITY MARKET
Grid connection: Use dynamic electricity tariffs subscription-free and provider-independent.
This means you can also benefit from favorable exchange prices.
PV/SOLAR
Self-generated electricity directly from the roof for your home. The cheapest and most climate-friendly kilowatt hour is home-made.
CONSUMER
Your home power station from E3/DC is the intelligent manager of your energy flows.
It controls your appliances and consumers according to your needs at all times.
E-MOBILITY
Your home power station masters the solar charging of e-vehicles perfectly, but also charges in a price-optimized way via the dynamic electricity tariff of your choice. Future as standard: With an E3/DC home power station, you are prepared for bidirectional charging.
As an energy center for buildings with high energy requirements, the S20 X PRO can be designed particularly flexibly, integrating large PV systems, offering extremely large storage capacities and a charging capacity of up to 30 kW.
Integrierte Schnittstelle
Als Energiezentrale für Gebäude mit hohem Energiebedarf ist das S20 X PRO besonders flexibel auslegbar.Das Hauskraftwerk integriert große PV-Anlagen, bietet extrem große Speicherkapazitäten und eine Ladeleistung bis 30 kW.
Powerful inverter integrated
Up to 45 kWp of PV power can be connected to the inverter in the S20 X PRO.
Ideal for farming solutions
A farm with several S20 X PROs offers even more storage capacity for all applications.
Load management
Controlled charging makes the vehicle fleet fast and cost-efficient.
Maximum Expansion Options
With the S20 X PRO, as with all home power stations, you have the option of retrofitting batteries for 5 years. But there's a lot you can do here: depending on the configuration, the storage system can grow to up to 328 kWh. And additional PV systems or charging stations can also be integrated.
S20 X PRO
System Overview
System capacity
Up to 122,3 kWh
Maximum expandable to
328 kWh
Charging power
23 to 30 kW
Emergency power with solar recharging
3-phase integrated
Warranty period
10 years
Energy management with AI 360°
integrated
Downloads
E3/DC-Brochure
With our brochure, you have all the important information at your fingertips at all times. Print it out or use it digitally and save raw materials too!
Product Comparison
Compare our home power station series in detail—if you have any questions, our support team will be happy to help!
Technical Specifications
Learn more about
energy independence!
S10 SE |
S10 X COMPACT |
S10 X |
|
| Für eine PV-Leistung bis (kWp) | 12,5 | 18 | 18 |
| Wechselrichter: AC-Ausgangsleistung (kW) | 8 | 12 | 12 |
| Lade-/Entladeleistung (kW) | 4,5 | 4,5 bis 6 | 9 bis 11 |
| Nutzbare Kapazität (kWh) | 5,25 bis 11,2 | 8,25 bis 11,2 | 17,4 bis 20,6 |
| Kapazität erweiterbar auf maximal (kWh) | 14 | 20,6 | 20,6 |
| Getrennte Aufstellung des Batteriesystems möglich | ja | ja | ja |
| 5 Jahre Nachrüstung möglich | ja | ja | ja |
| Zeitlich unbegrenzte Erweiterung im Farming möglich | ja | ja | ja |
| Not-/Ersatzstrom im Inselbetrieb | 3-phasig (Notstrombox) | 3-phasig (integriert) | 3-phasig (integriert) |
| Dauerversorgung (solares Nachladen) | ja | ja | ja |
| Gesamtgewicht (kg) | 116,5 bis 185,5 | max. 251 | max. 381 |
| Integriertes 360° Energiemanagement (kostenlose Updates) | ja | ja | ja |
| Solares Laden mit E3/DC-Wallbox | ja | ja | ja |
| Konformität mit §14a EnWG (EEBUS integriert) | ja | ja | ja |
| Systemgarantie (Jahre) | 10 | 10 | 10 |
